Plastic Board/Sheet/Film Extrusion Line
LOCATION:HOME > PRODUCT > Plastic Board/Sheet/Film Extrusion Line
Rigid/Soft PVC Sheets /PVC Transparent Sheets /UV imitation marble board Extrusion Line
1)PVC Sheets are easy to form, high tension, various colors, fireproof, high quality, low cost etc.
Rigid PVC sheets application: sandwich panel in construction fields, furniture edge banding and skinning, high standard printing, thermoforming packing etc.

2)Soft PVC sheets application: interior mats for automobiles, curtains, table cloth, liners for equipment, luggage, hardware and also interior decoration etc.

3))PVC Transparent Rigid Sheet Extrusion line
PVC transparent sheet have many advantages of fire-resistance, high quality, low cost, high transparent, good surface, no spot,less water wave, high strike resistance, easy to mould and etc. It is applied to different kinds of packing ,vacuuming and case, such as tools, toys, electronic, food, medicine and clothes.

4)UV imitation marble board:
a. Board surface coat imitation marble film, or laminate imitation marble and through curing treatment, good anti scratch, anti
scratch resistance.
b. Board with variety of color, it’s convenient to construct;
c. Instead of marble etc. natural stone in the interior decoration, with good aging resistance, anti-yellow, anti-ultraviolet ray ,green and environment , no radiation.
+86-532-86620998
13806392693(Mobile/Whatsapp/Wechat/)
Main Technical Specification

Model

Extruder model

Products width(mm)

Products thickness(mm)

Main motor power(kw)

Designed extrusion output(kg/h)

80/156-1500

80/156

1200

0.2-3.0

75

350

92/188-2200

92/188

2000

1.0-3.0

110

550
