Plastic Board/Sheet/Film Extrusion Line
LOCATION:HOME > PRODUCT > Plastic Board/Sheet/Film Extrusion Line
PP/PS Sheet Extrusion Line

PP/PS single layer, co-extrusion two color, double sides transparent sheets are used in thermoforming and packing industry. PP transparent sheet, dull polish sheet(coarse and fine), two color sheet and some other sheets are used in stationery industry.


PS electricity conductive sheet mainly used for packing of semi-conductive electric components, computer products which require no dust, not static-electricity, no radio frequency or facilities.

+86-532-86620998
13806392693(Mobile/Whatsapp/Wechat/)
Main Technical Specification
Model LM150/120/90 LM150/60 LM130/60 LM120 LM100
Product width 1500mm 1000mm 900mm 800mm 600mm
Product thickness 0.3-2mm 0.3-2mm
0.3-2mm
0.2-.2mm 0.1-0.8mm
Capacity 800-1000kg/h 800kg/h 550-600kg/h 350-400kg/h 200-250kg/h
Designed line speed 60m/min 40m/min 30m/min 25m/min 20m/min
Calender diameter 900mm 700mm 600mm 500mm 400mm
Note: The specifications are subject to change without prior notice.
Video
Application
